WFJ Superfine Grinder

WFJ series superfine grinder machine is made up of main engine, auxiliary engine, three electric control parts, characteristics, such as winnowing, screen or mesh, a uniform partical size and other performance, continuous production process, can deal with such as chemicals, food, medicine, pharmaceutical, cosmetic, plastic, dye, resin, pigments, grains and other material crushing.

Product Features :

• Compact design, reasonable structure, the machine is equipped with internal grading mechanism, so that the crushing, grading a complete, in order to reduce the energy loss caused by crushing
• The system is equipped with induced draft fan, which can continuously discharge the heat generated in the machine during crushing operation, so it can adapt to the crushing of heat-sensitive materials
• Strong adaptability, with narrow particle size distribution, product particle size uniformity, fineness up to 10-sum
• In the case of no shutdown, adjust the speed of the classifier or adjust the air volume, can get the required particle size, uniform distribution of products
• The upper cover of the main engine is opened with an air spring, and the fuselage adopts a blowing structure, so that the fuselage can be opened to both sides, so there is no obstacle to clean and maintain the internal parts
• The main grinding parts are made of advanced alloy tool steel, which can greatly prolong the service life of worn parts and prolong the replacement cycle
• The bearing system adopts foreign imported high-speed precision bearings, the rotor as a whole to do dynamic balance, so that the whole machine running smoothly, small vibration, low noise
• The pipe connection is made of Shaanxi disassembly structure, which can be disassembled and cleaned quickly and conveniently
• Equipped with cyclone separator and dust collector, no dust in the production process; Dust trap bag can effectively intercept the micro powder in the air flow, so that the exhaust emission meets the requirements of clean environmental protection
• Dust trapping bag interception of fine powder can be effectively recovered, reduce the material loss rate

Working Principle

The material enters the crushing chamber through the hopper and is shear and crushed by the high-speed rotating blade. The powder enters the grading chamber through the guide ring. Because the grading wheel is rotating, the powder flowing into the leaf passage is under the action of aerodynamic force and centrifugal force at the same time. The particles larger than the critical diameter (graded particle size) in the powder are thrown back to the crushing chamber to continue crushing because of the large mass, and the particles smaller than the critical diameter enter the cyclone separator and bag filter through the method of negative pressure air transport through the discharge pipe, and the discharged material meets the requirements of the product.

Diagram of machine structure ( complete set ) :
